GUIDE TO INSTALLATION AND OPERATION
14 | Kaleido-Solo
5.1 Status Menu
Category Description
General Input Shows the selected input: Electrical (BNC) or Optical (SFP module).
Shows the format detected as specified in section 4.1.1.
SFP Module Shows the type of external module detected and supported (None, Dual TX,
Dual RX, RX, TX or RX-TX). See SFP.
Aspect Ratio Shows the AFD/VLI/WSS aspect ratio video processing applied at the
output. This parameter can be changed in the Metadata section.
Monitor (Video) Shows the monitor‟s preferred resolution specified by EDID; see section
5.11. See section 4.1.1 for a complete list of possible values.
Monitor (Audio) Shows the monitor audio support status specified by EDID; see section
5.11.
Possibilities are: No Audio Support, Linear PCM, AC-3, MPEG1, MP3,
MPEG2, AAC, DTS, ATRAC, One Bit Audio, Dolby Digital+, DTS-HD, MAT
(MLP), DST, WMA Pro, Format Unknown.
