GUIDE TO INSTALLATION AND OPERATION
Kaleido-Solo | 15
Output (HDMI Video)
Shows the actual output resolution at the HDMI output. See section 4.1.1 for
a complete list of possible values.
Output (HDMI Audio)
Shows the actual audio state at the HDMI output.
Possibilities are: Stereo, 5.1 no.1 Downmixed, 5.1 no.2 Downmixed, 5.1
no.1, 5.1 no.1. Muted (NPCM), 5.1 no.2, 5.1 no.2 Muted (NPCM), Audio
Driver Off, Muted
Output
(SPDIF/Analog)
Shows the current state of the SPDIF/Analog audio output.
Possibilities are: Stereo, 5.1 no.1 Downmixed, 5.1 no.2 Downmixed,5.1 no.1
Muted (NPCM), 5.1 no.2 Muted (NPCM), Muted.
Input
Embedded
Audio
1 to 16
Shows the type of audio detected per channel (PCM, NPCM, AC3, E-AC3,
DOLBY E, MPG1L1, MPG1L2/3, MPG2 aud, MPG2L1, MPG2L2/3, AAC,
HE-AAC, or N/A). A silence is represented by a yellow text color and an
(NSD) next to the audio type. NSD stands for No Signal Detected.
The Monitor resolution can be different than the Output resolution but in most cases both resolutions will be the same.
