Menu List
91
13: PRESET MEMORY
Menu item Value (bold text: default value) Explanation
LOAD
1: MEMORY 1 –
30: MEMORY 30 (*12)
Selects the preset memory to load.
Pressing the [VALUE] knob lets you load the preset memory.
When “MEMORY” is selected on the [MODE] button, you can use the MEMORY [1]–[10] buttons to
recall preset memories 1–10.
SAVE
1: MEMORY 1 –
30: MEMORY 30 (*12)
Selects a preset memory for saving settings.
Pressing the [VALUE] knob lets you save the settings to the preset memory.
When “MEMORY” is selected on the [MODE] button, you can long-press the MEMORY [1]–[10]
buttons to save the settings to preset memories 1–10.
* The following settings are not saved in preset memory.
¹ PRESET MEMORY menu
¹ MACRO menu
¹ SEQUENCER menu
¹ STILL IMAGE menu
¹ FREEZE menu
¹ AUTO SWITCHING menu
¹ CTL/EXP menu
¹ RS-232/TALLY/GPO/GPI menu
¹ LAN CONTROL menu
¹ CAMERA CONTROL menu
¹ USB MEMORY menu
¹ SYSTEM menu
INITIALIZE
ALL, 1: MEMORY 1 –
30: MEMORY 30 (*12)
Selects the preset memory to be initialized.
Press the [VALUE] knob to initialize the preset memory.
NAME EDIT
1: MEMORY 1 –
30: MEMORY 30 (*12)
Selects the preset memory to be renamed.
Press the [VALUE] knob to access the screen for editing the name.
START UP
Specifies the settings loaded at startup.
LAST MEMORY
Restores the state that was in effect immediately before the power was turned off (Last Memory
feature).
The current settings (Last Memory values) are saved every 4 seconds, and when you exit a menu.
1: MEMORY 1–
30: MEMORY 30 (*12)
Recall the settings at the selected preset memory.
MEMORY PROTECT OFF, ON
When this is “ON,” prohibits settings from being saved or initialized. This protects the preset memories.
* Protected preset memories are erased if you perform a factory reset.
NUMBER OF MEMORY SW
When “MEMORY” is selected on the [MODE] button, this sets how many buttons function as memory selection buttons.
10 Preset memory 1–10: MEMORY [1]–[10] buttons
30
Preset memory 1–10: MEMORY [1]–[10] buttons
Preset memory 11–20: PGM/A [1]–[10] buttons
Preset memory 21–30: PST/B [1]–[10] buttons
FADE TIME 0 .0– 4.0sec
Sets how long the transition to the next video takes when recalling a preset memory.
* The time you set is used for the parameters below.
MIX/WIPE OFF, ON When this is “ON,” the transition effect is applied when the preset memory is recalled.
PinP & KEY 1–4 OFF, ON
When this is “ON,” the inset screen fades in when you recall a preset memory that includes a PinP
composite.
DSK 1, 2 OFF, ON
When this is “ON,” the superimposed caption and video fades in when you recall a preset memory
that includes a DSK composite.
LOAD PARAMETER
Specifies whether to recall the following items when recalling a preset memory.
Items that are turned off are excluded from the preset memories that are recalled.
VIDEO ASSIGN OFF, ON VIDEO ASSIGN menu
VIDEO INPUT OFF, ON VIDEO INPUT menu
VIDEO OUTPUT OFF, ON VIDEO OUTPUT menu
TRANSITION TIME OFF, ON TRANSITION TIME menu
MIX/WIPE OFF, ON MIX/WIPE menu
SPLIT OFF, ON SPLIT menu
PinP & KEY OFF, ON PinP menu
DSK OFF, ON DSK menu
VIDEO CROSSPOINT OFF, ON Cross-point button state
VIDEO FADER INITIALIZE , ON
Video fader position
When set to “INITIALIZE,” the video fader position is recalled when the video fader is pushed all the
way up or pulled all the way down.
AUDIO INPUT OFF, ON AUDIO INPUT menu
AUDIO OUTPUT OFF, ON AUDIO OUTPUT menu
AUDIO FOLLOW OFF, ON AUDIO FOLLOW menu
AUDIO AUTO MIXING OFF, ON AUDIO AUTO MIXING menu
(*12) If you edited a preset memory’s name using “NAME EDIT,” the edited name is shown.
