High-Definition Focus Magnifier
Function
You can magnify the display for the viewfinder
screen or Monitor output.
By pressing the FOCUS MAG button of the
viewfinder (DVF-EL200, DVF-L700) attached
to the unit, or pressing an assignable button
assigned with the VF Focus Magnifier function,
you can expand the center part of the
viewfinder screen, making it is easier to adjust
the focus. By pressing an assignable button
assigned with the Monitor Focus Magnifier
function, you can expand the center part of
the Monitor output image, making it is easier
to adjust the focus.
The magnified display does not affect the
recorded image or other output signals, other
than the Monitor output.
Normal focus magnification reduces the
resolution because it simply magnifies a
part of the displayed image. However, the
two-times (×2) focusing by the unit provides
focus magnification while maintaining the
display resolution by cutting out the portion
to magnify from the 4K image instead of the
recorded image or other output signals, other
than the Monitor output.
Four-times (×4) focus magnification selection
is also supported using the 4K image cutout
function.
The following focus magnification functions
can be assigned to an assignable button
(page 48).
Viewfinder focus magnifier function: VF Focus
Magnifier
Monitor output focus magnifier function:
Monitor Focus Magnifier
The magnification sequence of the FOCUS
MAG button and assignable buttons assigned
with a focus magnification function is set
using the following items.
Viewfinder screen: Monitoring > VF Display >
VF Magnifier Ratio (page 78) in the full
menu
Monitor output: Monitoring > Output Display >
Monitor Magnifier Ratio (page 77) in the
full menu
When VF Magnifier Ratio is set to Ч2.0/Ч4.0,
the magnification sequence each time you
press an assignable button assigned with VF
Focus Magnifier is Ч2.0
 Ч4.0  Ч1.0 
Ч2.0.
Similarly, when Monitor Magnifier Ratio is set
to Ч2.0/Ч4.0, the magnification changes each
time you press an assignable button assigned
with Monitor Focus Magnifier.
[Notes]
• In High Frame Rate mode (shooting frame rate of
61 fps or higher), the Ч2/Ч4 focus display image
resolution decreases because cutout display from a
4K image is not supported.
• When Project Frame Rate is set to 59.94 or 50 and
the Monitor output setting is 1920×1080P, Monitor
Magnifier Ratio cannot be set to ×4.0 or Ч2.0/Ч4.0.
When the Monitor output setting is 1920×1080i,
Monitor Focus Magnifier does not function.
• Monitor Focus Magnifier is also applied to the HDMI
output if the HDMI output has the same output
format as the Monitor output. You can check the
setting using Monitoring > Overlays/Frame Line >
HDMI (page 79) in the full menu. The HDMI output
is the same as the Monitor output if HDMI is set to
“Same as Monitor”.
Operation of assignable buttons
assigned with focus magnifier functions
You can set whether an assignable button
assigned with a focus magnifier function
will toggle the function on/off each time the
button is pressed or turn the function on only
while the button is pressed.
Viewfinder screen: Monitoring > VF Display
> VF Magnifier Mode (page 78) in the full
menu
Monitor output: Monitoring > Output Display
> Monitor Magnifier Mode (page 77) in the
full menu
Highlight Clip Indicator
You can display clipped highlight areas in red
in the Monitor output image and viewfinder
output image.
Press the assignable buttons (pages 48,
50) assigned with Monitor Highlight Clip
Ind and VF Highlight Clip Ind to switch the
highlight clip indicators on/off.
[Note]
Highlight clip indicators do not function when Technical
> Special Configuration > RM/RCP Paint Control
(page 91) is set to On in the full menu.
High Key / Low Key
You can check for blown-out highlights and
blocked-out shadows in the Monitor output
image and viewfinder output image.
Enable High Key to differentiate areas of high
luminance, making them easier to see, to
check for blown-out highlights.
Enable Low Key to differentiate areas of low
luminance, making them easier to see, to
check for blocked-out shadows.
Press assignable buttons 1 to 4 (page 50)
assigned with Monitor High/Low Key and VF
High/Low Key to switch the high key and low
key settings.
[Note]
High/Low key does not function when Technical
> Special Configuration > RM/RCP Paint Control
(page 91) is set to On in the full menu.
False Color Display
You can display false color in the viewfinder by
pressing the B/False Color button (DVF-EL200)
or SPARE button (DVF-L700) on the viewfinder
attached to the unit.
You can also display false color on the monitor
output.
Display
color Signal level
S-Log3 (default)
S-Log2 (PMW-F55
reference value)
Red 93.4% to 96.1% 105.5% to 109.5%
Yellow 91.3% to 93.4% 102.5% to 105.5%
Orange 87.7% to 90.6% 97.4% to 101.5%
Pink 54.3% to 58.0% 50.2% to 55.2%
Light
pink 47.8% to 50.8%
(18% gray + 1 stop) 41.5% to 45.4%
(18% gray + 1 stop)
Cyan 43.8% to 46.5% 36.3% to 39.6%
Green 38.9% to 42.2%
(18% gray) 30.4% to 34.4%
(18% gray)
Light
blue 24.6% to 34.4% 15.5% to 25.2%
Blue 3.5% to 5.6% 3.0% to 4.0%
Purple –7.3% to 3.5% –7.3% to 3.0%
• You can set whether to use the preset on/
off setting and threshold of each false color
in the viewfinder and monitor output, or to
set colors manually using Technical > False
Color (page 90).
• You can turn the false color function display
in a viewfinder on/off by pressing an
assignable button assigned with VF False
Color.
• You can turn the false color function
display on a monitor on/off by pressing an
assignable button assigned with Monitor
False Color.
[Note]
The false color function does not operate when
Technical > Special Configuration > RM/RCP Paint Control
(page 91) is set to On in the full menu.
