3. Camera Operations: Monitoring Menu 80
Monitoring > Overlays/Frame Line
Makes settings related to information and frame lines superimposed on each output signal.
On/Off setting is selected using a checkbox (excluding Frame Line on Playback).
On: Checkbox selected
Off: Checkbox cleared
Menu item Setting Description
Level Gauge
Info. A ( On /Off)
Info. B (On/ Off )
Selects whether to display the spirit level
information graphically in the output
information set for Overlay A and Overlay B.
[Note]
Level Gauge is grayed out and cannot be operated
when a CBK-3610XS is connected to the unit.
Lens Status
Info. A ( On /Off)
Info. B ( On /Off)
Option (Meter/ Feet )
Selects whether to display the lens
information in the output information set for
Overlay A and Overlay B.
Selects the focus position display units.
Remote Control Status
Info. A ( On /Off)
Info. B (On/ Off )
Selects whether to display the remote control
status information in the output information
set for Overlay A and Overlay B.
Monitoring > Overlays/Frame Line
Makes settings related to information and frame lines superimposed on each output signal.
On/Off setting is selected using a checkbox (excluding Frame Line on Playback).
On: Checkbox selected
Off: Checkbox cleared
Menu item Setting Description
Frame Line A/B
Setup Color
Option ( White /Yellow/
Cyan/Green/Magenta/
Red/Blue)
Sets the display color of frame lines.
Center Marker
Line A ( On /Off)
Line B ( On /Off)
Option ( Cross /Open
Cross/Dot)
Selects whether to display the center marker
in the output information set for Frame Line A
and Frame Line B.
Selects the display form (Cross/Open Cross/
Dot) of the center marker.
Picture Area
Line A ( On /Off)
Line B ( On /Off)
Selects whether to display the picture area in
the output information set for Frame Line A
and Frame Line B.
Aspect Ratio
Line A ( On /Off)
Line B ( On /Off)
Option (17:9/ 16:9 /15:9/
14:9/13:9/9:16/4:3/1:1/
1.43:1/1.66:1/1.85:1/2:1/
2.35:1/2.39:1)
Selects whether to display the aspect ratio
marker in the output information set for
Frame Line A and Frame Line B.
Selects the mode (17:9/16:9/15:9/14:9/13:9/
9:16/4:3/1:1/1.43:1/1.66:1/1.85:1/2:1/2.35:1/
2.39:1) when displaying the aspect ratio
marker.
Aspect Ratio Type
Option ( Line /Mask/
Line&Mask)
Selects the display form of the aspect ratio
marker.
Line: Displays lines with color set by Color.
Mask: Displays a lower video signal level for
areas outside the marker area.
Line&Mask: Displays lines with color set by
Color and a lower video signal level for
areas outside the marker area.
Surround View Type
Option ( Line /Mask/
Line&Mask)
Selects the display form of the Surround View
marker.
Line: Displays the recording area using lines.
Mask: Displays the recording area by masking
(reducing) the video signal level outside
the recording area.
Line&Mask: Displays the recording area using
lines and by masking (reducing) the video
signal level outside the recording area.
Mask Level
Option (0 to 15 ( 12 ))
Selects the brightness of the image outside
the marker when Aspect Ratio Type or
Surround View Type is set to Mask.
