3. Camera Operations: User Functions Screen 51
Assignable Button
setting Function State after rebooting
Monitor High/Low
Key
1)
Selects the Monitor output mode.
Switches between High Key (screen for
checking for blown-out highlights)
 Low
Key (screen for checking for blocked-out
shadows)
 Off (normal display) each time
the button is pressed.
Setting not retained
Monitor False Color 1) Turns the false color function display on a
monitor on/off. Setting retained
VF Frame Line Turns superimposition of frame lines on the
viewfinder/monitor screen output image on/
off. Setting retained
VF Overlay Turns the information display on the
viewfinder/monitor screen output image on/
off. Setting retained
Press & Hold for VF
Log
6)
Disables the LUT applied to the viewfinder/
monitor screen output image while the
button is pressed for normal image quality
without applying a LUT. Setting not retained
VF Focus Magnifier Turns the focus magnifier function of the
viewfinder on/off. Setting not retained
VF Highlight Clip Ind 1) Turns the function to display clipped highlight
areas in red in the viewfinder on/off. Setting retained
VF High/Low Key 1) Selects the viewfinder output mode.
Switches between High Key (screen for
checking for blown-out highlights)
 Low
Key (screen for checking for blocked-out
shadows)
 Off (normal display) each time
the button is pressed.
Setting not retained
VF False Color 1) Turns the false color function display in a
viewfinder on/off. Setting retained
VF Zebra Turns the zebra function of the viewfinder/
monitor screen output image on/off. Setting retained
Line A: Aspect Ratio
Disp. Turns the Aspect Ratio display for Line A on/
off. Setting retained
Line B: Aspect Ratio
Disp. Turns the Aspect Ratio display for Line B on/
off. Setting retained
Assignable Button
setting Function State after rebooting
Line A: User Frame
Disp. Turns the User Frame Line 1 and User Frame
Line 2 display for Line A on/off.
Each time the button is pressed, the display
switches between User Frame Line 1 and 2
display
 User Frame Line 1 display  User
Frame Line 2 display  User Frame Line 1 and
2 hidden.
Setting retained
Line B: User Frame
Disp. Turns the User Frame Line 1 and User Frame
Line 2 display for Line B on/off.
Each time the button is pressed, the display
switches between User Frame Line 1 and 2
display
 User Frame Line 1 display  User
Frame Line 2 display  User Frame Line 1 and
2 hidden.
Setting retained
H & V Flip 8) Flips the shooting mode image orientation. Setting retained
Anamorphic De-
Squeeze Changes the Project > Basic Setting > Anamo.
De-Squeeze setting in the full menu.
Each time the button is pressed, the setting
changes to the next item in the list of menu
selection options. Setting retained
Auto White Balance 5) Executes auto white balance. –
Color Bars 5) Turns color bars on/off. Setting retained
Rec Starts/stops recording. –
Rec Review Executes the Rec Review function. Setting not retained
Picture Cache Rec Turns the picture cache recording function
on/off. Setting retained
AXS Slot Change Switches the active slot when two AXS
memory cards are inserted.
Switches between A and B each time the
button is pressed. Setting retained
ND +1stop Switches the ND filter one stop in the darker
direction. –
ND -1stop Switches the ND filter one stop in the brighter
direction. –
