137 8. Appendix
Error/Warning Indications
If a warning, caution, or operating condition that requires confirmation occurs on the unit, a
message is displayed on the sub display, the REC lamp starts flashing, and a warning sound is
emitted.
The buzzer is output to the built-in speaker or to the headphones connected via the headphone
connector.
When the unit is turned on, a message appears on the sub display screen prompting you
to execute Auto Pixel Restoration if the auto adjustment for the image sensor (Auto Pixel
Restoration) has not been performed for a certain period of time. In this case, follow the on-
screen instructions to execute Auto Pixel Restoration (page 87).
Error Display
The unit will stop operation when the following kind of display occurs.
Error display
indication Buzzer REC lamp Cause and Solution
E + Error code Intermittent High-speed
flashing
The unit may be defective. Recording stops even
if
 REC is displayed on the viewfinder/monitor
screen.
Turn off the power and check the connected
equipment, cables, and media. If the error
persists when the unit is turned on again,
contact your Sony service representative. (If
power cannot be turned off by setting the power
switch to OFF, remove the battery pack or the DC
IN source.)
Warning Display
When one of the following messages occurs, use the following table to resolve the problem.
Warning display
indication Buzzer REC lamp Cause and Solution
Media Full 1) Continuous High-speed
flashing
Clips could not be recorded, copied, or split
because there is no remaining capacity on the
AXS memory card.
Replace immediately.
Battery End 1) Continuous High-speed
flashing
The battery pack is dead. Recording is disabled.
Stop operation and recharge the battery pack.
Warning display
indication Buzzer REC lamp Cause and Solution
Temperature High 1) Intermittent Flashing The internal temperature is high.
Turn off the unit and allow it to cool down before
operating it again.
Insufficient Voltage 1) Continuous High-speed
flashing
The DC IN voltage is too low. Recording is
disabled.
Connect another power source.
1) Message is not displayed on the monitor screen.
About temperature warnings
The Temperature High warning may be displayed when operating within the guaranteed
operating temperature of the unit, depending on the operating mode and usage environment.
Recording does not immediately stop when these messages are displayed, but the suggestions
given in the Cause and Solution column of the table should be implemented promptly.
Caution and Operation Confirmation Display
The following caution and operation confirmation messages may appear on the monitor screen
or sub display, and warning icons may be displayed and messages displayed in the Info category
> Camera Condition in the menu. Follow the instructions provided to resolve the issue.
Display indication Cause and Solution
Backup Battery End
Please Change The remaining capacity of the backup battery is
insufficient.
Replace the backup battery.
Cannot Use AXS(A)*
Please Change A memory card that has been partitioned or a
memory card containing more clips that can be
handled by the unit was inserted.
The card cannot be used in the unit, and must be
replaced.
Cannot Use AXS(A)*
Unsupported File System A card using a different file system or an
unformatted card was inserted.
The card cannot be used in the unit, and must be
replaced or formatted using the unit.
Media Error
AXS(A)* Needs to be Restored An error occurred with the memory card. The card
requires restoration.
Restore the card.
