65 3. Camera Operations
Shooting Menu
The functions and available settings of each menu item are given below.
Default values are shown underlined and in
bold text.
Shooting > FPS
Sets the shooting frame rate.
Menu item Setting Description
Fixed/Variable Select Fixed /Variable Selects whether the FPS setting is set to
constant speed shooting or variable speed
shooting.
FPS Select When Fixed/Variable Select is
set to Fixed, one of the
following values is displayed.
Fixed 23.98/Fixed 24.00/
Fixed 25.00/Fixed 29.97/
Fixed 47.95/Fixed 50.00/
Fixed 59.94
Selects the shooting frame rate.
The default values vary as shown below
depending on the Project Frame Rate setting.
Project
Frame
Rate Default when
Fixed/Variable
Select is
Variable Display value
when Fixed/
Variable Select
is Fixed
59.94 60 Fixed 59.94
50 50 Fixed 50.00
47.95 48 Fixed 47.95
29.97 30 Fixed 29.97
25 25 Fixed 25.00
24 24 Fixed 24.00
23.97 24 Fixed 23.98
[Note]
Shooting frame rates of 7 or lower cannot be set in
the following cases.
– When Base ISO is set to ISO 3200
– When Base ISO is set to ISO 2500 and the
recording format is ProRes
Shooting > Shutter
Makes settings related to the electronic shutter.
[Note]
Shutter is grayed out and cannot be operated when an RM-B170 or other remote control unit is connected and
Technical > Special Configuration > RM/RCP Paint Control (page 91) is set to On in the full menu.
Menu item Setting Description
Shutter Select When Shutter Mode
(page 87) is set to Speed
Default selection options
1/24, 1/25, 1/30, 1/48, 1/50,
1/60, 1/100, 1/120, 1/250,
1/500, 1/1000, 1/2000
1)
When Shutter Mode
(page 87) is set to Angle
Default selection options
360.0/ 180.0 /172.8/144.0/
90.0/45.0/22.5/11.2/5.6
When Step/Cont. Select is set
to Continuous, the selection
range is 360.0 to 4.2 (Angle) or
1/24
1) to 1/8000 2) (Speed).
Selects shutter angle or speed of the
electronic shutter.
The default speed values for different Project
Frame Rate (page 72) settings are given
below.
23.98/24: 1/24
25: 1/25
29.97: 1/30
47.95: 1/48
50: 1/50
59.94: 1/60
1) The options are 1/60 and subsequent values
when the project frame rate is 59.94, 1/50
and subsequent values when 50.0, 1/30 and
subsequent values when 29.97, and 1/25 and
subsequent values when 25.0.
2) The options are 1/7000 and preceding values
when the project frame rate is 50.0 or 25.0, and
1/6000 and preceding values when 24.0 or 23.98.
Step/Cont. Select Step /Continuous Selects whether the electronic shutter values
are step values or continuous.
Add/Change Step Adds or edits a selection option available in
Shutter Select in Step mode.
Up to 16 selection options can be added.
Delete Step Deletes a selection option available in Shutter
Select in Step mode.
Shooting > Flicker Reduce
Makes settings related to flicker reduction.
Menu item Setting Description
Mode On/ Off Turns the flicker reduction function on/off.
Frequency 50Hz/ 60Hz Sets the power supply frequency of lighting
causing flicker.
