SDI OUT Connector Output Formats
The serial digital signal from an SDI OUT connector is output according to the Project category and Monitoring category settings in the menu.
For details about Project category settings combinations, see “Recording Format Settings” (page 59).
You can set the 3G SDI output format to Level A or Level B using Monitoring > Output Format > 3G SDI 1/2/3/4 Output (page 77) in the full menu.
Default values are shown underlined and in bold text.
Project Monitoring > Output Format Output format
Project Frame Rate Imager Mode Recording Format SDI 1/2 SDI 3/4 SDI 1 SDI 2 SDI 3 SDI 4
59.94/50 8.2K 17:9/
6K 3:2/
6K 1.85:1/
6K 17:9/
6K 2.39:1/
5.8K 6:5/
5.8K 17:9/
4K 6:5/
4K 4:3/
4K 17:9/
4K 2.39:1 X-OCN XT
X-OCN ST
X-OCN LT
ProRes 4444 4K
ProRes 422 HQ 4K
4096×2160P 12G
1920×1080P Level A 1)
4096×2160P
YPbPr 12G
4096×2160P
YPbPr 12G
1920×1080P
YPbPr 3G Level A
1920×1080P
YPbPr 3G Level A
1920×1080i
1920×1080i
YPbPr 1.5G
1920×1080i
YPbPr 1.5G
4096×2160P
Square Level B
2)
4096×2160P
Square Level B
2)
4096×2160P YPbPr 3G Square Level B
4096×2160P
2SI Level B
2)
4096×2160P
2SI Level B
2)
4096×2160P YPbPr 3G 2SI Level B
2048×1080P Level B 2)
1920×1080P Level B 2)
2048×1080P
YPbPr 3G Level B
2048×1080P
YPbPr 3G Level B
1920×1080P
YPbPr 3G Level B
1920×1080P
YPbPr 3G Level B
1920×1080i
1920×1080i
YPbPr 1.5G
1920×1080i
YPbPr 1.5G
1920×1080P Level B 2)
1920×1080P Level B 2)
1920×1080P
YPbPr 3G Level B
1920×1080P
YPbPr 3G Level B
1920×1080P
YPbPr 3G Level B
1920×1080P
YPbPr 3G Level B
1920×1080i
1920×1080i
YPbPr 1.5G
1920×1080i
YPbPr 1.5G
1920×1080i 1920×1080i
1920×1080i
YPbPr 1.5G
1920×1080i
YPbPr 1.5G
1920×1080i
YPbPr 1.5G
1920×1080i
YPbPr 1.5G
Recording Formats and Output Signals
