99 3. Camera Operations
Clip Operations on the Mini Display
You can play a clip by selecting the clip to play
from the clip screen displayed on the mini
display.
Clip Screen
Press the CLIPS button (page 9) on the
Operator side to display the clip screen for
playable media on the mini display.
7
6
5
1
2
3
4
1. Playback status indicator
Displays the clip playback status.
2. Active playback media
Displays the active playback media of the
selected clip.
3. Clip name indicator
Displays the clip name of the selected clip.
4. Clip position in playback media
Displays the clip number/total number of the
selected clip.
5. F Fwd/Next button
Jumps to the next clip when the button
(ITEM key 3) is pressed while playback is
paused.
Fast forwards the clip when the button
(ITEM key 3) is pressed during playback.
6. Play/Pause button
Plays/pauses clip playback when the
button (ITEM key 2) is pressed.
7. F Rev/Prev button
Jumps to the previous clip when the button
(ITEM key 1) is pressed while playback is
paused.
Fast reverses the clip when the button
(ITEM key 1) is pressed during playback.
Playback
You can play recorded clips while the unit is in
standby mode.
1
Insert the AXS memory card to play.
2
Press the CLIPS button (page 9) on
the Operator side.
The active playback clip appears on the
mini display.
3
Use the Prev button (ITEM key 1) or Next
button (ITEM key 3) to select a clip to play.
4
Press the Play/Pause button (ITEM key 2).
The playback image appears on the
viewfinder/monitor screen.
Playback operations
Playback operation is performed using the
buttons on the mini display (page 99).
Play/Pause button: Pause playback. To resume
playback, press this button again.
F Fwd button/F Rev button: Fast forward/
reverse. To return to normal playback, press
the Play/Pause button.
Monitoring audio
In normal playback mode, you can monitor the
recorded audio through the built-in speaker
(page 9) or connected headphones.
When headphones are connected to the
headphones connector (page 9), the built-
in speaker is turned off.
You can select the channel to monitor and
adjust the volume using Audio category >
Monitor CH and Monitor Level (page 57) in
the menu.
Switching between AXS memory cards
When two AXS memory cards are loaded,
press the SLOT SELECT button (page 9) to
switch memory cards. When the clip list screen
is displayed on the sub display, you can also
press ITEM key 1 on the sub display to switch.
[Note]
You cannot switch AXS memory cards during playback.
Continuous playback of cards in slots A and B is not
possible.
