Hardware Preparation and Installation
MVME55006E Single Board Computer Installation and Use (6806800A37J)
25
Items in brackets are factory default settings.
J34, J97,
J98, J99
Ethernet 2 Selection
Headers
(see also J6, J100, J7, J101)
Refer to a note on page
for a configuration
limitation.
1-2 on all
Rear P2 Ethernet
(set when in SBC/IPMC761
mode)
[No jumpers installed] Front-panel Ethernet
J102 –
J110
P2 I/O Selection Headers
1-2
[2-3]
PMC 2 I/O connected to P2
IPMC I/O connected to P2
Table 1-2 MVME5500 Jumper Settings (continued)
Jumpers /
Switches
Function
Settings
