ALS
380
2.1.4
Design versions
The ALS 380 labeller is available in 4 different versions,
depending on the taskat hand:
Top-labeller right-hand version
– Labelling from above onto the upper side of the
product [3].
– The products are conveyed from left to right.
– The dispensing edge is located on the right side.
Side-labeller right-hand version
– Labelling from the side onto one of the product’s
sides [4].
– The products are conveyed from left to right.
– The dispensing edge is located on the right side.
[3] Top-labeller right-hand version
A ALS 380 labeller
B Product on conveyor line
C Labelled product
[4] Side-labeller right-hand version
A ALS 380 labeller
B Product on conveyor line
C Labelled product
A
B
C
A
B
C
