52
4 O
PERATION
4.4 S
ETTINGS IN THE EXTENDED MENU
ALS
380
4.4.1 Overview
[54] Functions in the extended menu of the ALS 380
Function/dis-
play Brief description
ON The machine is ready for operation / start dispensing labels
OFF Stop/end the label dispensing
INIT Automatic material initialisation
VELO Dispensing speed
STOD Distance between dispensing edge and leading edge of the label
POS Distance between leading edge of product (product sensor) and label
POS 2 Distance between the leading edges of the first and second label on the same product
POS 3 Distance between the leading edges of the second and third label on the same product
VERT Relationship between the dispensing speed and the conveyor belt speed
CONT Adjust the label stop sensor
E–SS Distance between label stop sensor and dispensing edge
LPIT Label distance
PRDL Product length
P_S_ Polarity of the product sensor
S_S_ Polarity of the label stop sensor
MLAB Allowable number of unlabelled products
EGRA Compensation factor for RPM transmitter when operating with automatic dispensing speed
adjustment
(not with ALS 380 HS, see Service Guide)
TMOD Activate and deactivate tandem operation
LOAD Loading product data banks
SAVE Create and save a product data bank
DEL Deleting a product databank
QUIT Exit the extended menu
