A.3.6 C-Band 1:1 Redundancy Switch/Waveguide Kit (CEFD P/N KT/12201-1)
Table A-9. C-Band 1:1 Redundancy Switch/Waveguide Kit (CEFD P/N KT/12201-1) Parts List
ITEM QTY CEFD P/N DESCRIPTION
1 1 FP/BR12242-1 Bracket, Mounting (ROHS)
2 4 GA/CPA-137-R-H-C Gasket, Half-Thickness
3 4 GA/CPR-137-R-F-C Gasket, Full-Thickness
4 1 RF/C-TERM1000W Termination, Load
5 2 FP/WG12241-1 Waveguide, Straight (ROHS)
6 1 SW/WG-3NAFS-COLD Switch, CPR137
7 1 FP/WG11796-1 Waveguide, Left
8 1 FP/WG11797-1 Waveguide, Right
9 2 HW/3/8SPRINGNUT Springnut
10 64 HW/10-FLT Washer, Flat
11 64 HW/10-SPLIT Washer, Split
12 64 HW/10-32X5/8SHC Screw, Cap
13 2 HW/3/8-FLT Washer, Flat
14 2 HW/3/8-SPLIT Washer, Split
15 2 HW/3/8-16X1BLT Bolt, Hex-Head
16 1 FP/WG12419-1 Spacer, Waveguide
