L3149B (C200) Advanced Tone Remote Desk Set Programming
55
Two-Tone Paging
Two-Tone Codeplan
Allows the selection of the Two-Tone Codeplan from the following list. Please refer to the Tone Group
Frequency Chart and the Code Plan Chart below for the specifics for each codeplan.
N OTE : This parameter affects alias paging as well.
Tone Group Frequency Chart
Tone
Group #
0 1 2 3 4 5 6 7 8 9
Group
No.
1
330.5 349.0 368.5 389.0 410.8 433.7 457.9 483.5 510.5 539.0 1
2
569.1 600.9 634.5 669.9 707.3 746.8 788.5 832.5 879.0 928.1 2
3
1092.4 288.5 296.5 304.7 313.0 953.7 979.9 1006.9 1034.7 1063.2
3
4
321.7 339.6 358.6 378.6 399.8 422.1 445.7 470.5 496.8 524.6 4
5
553.9 584.8 617.4 651.9 688.3 726.8 767.4 810.2 855.5 903.2 5
6
1122.5 1153.4 1185.2 1217.8 1251.4 1285.8 1321.2 1357.6 1395.0 1433.4
6
A
358.9 398.1 441.6 489.8 543.3 602.6 668.3 741.3 822.2 912.0 7
B
371.5 412.1 457.1 507.0 562.3 623.7 691.8 767.4 851.1 944.1 8
Z
346.7 384.6 426.6 473.2 524.8 582.1 645.7 716.1 794.3 881.0 9
GE(A) 682.5 592.5 757.5 802.5 847.5 892.5 937.5 547.5 727.5 637.5 A
GE(B) 652.5 607.5 787.5 832.5 877.5 922.5 967.5 517.5 562.5 697.5 B
GE(C) 667.5 712.5 772.5 817.5 862.5 907.5 952.5 532.5 577.5 622.5 C
Plectron 643.0 910.0 1036.0 1082.0 1130.0 1287.0 1465.0 1820.0 1985.0 2688.0 D
10 1472.9 1513.5 1555.2 1598.0 1642.0 1687.2 1733.7 1781.5 1830.5 1881.0 E
11 1930.2 1989.0 2043.8 2094.5 2155.6 2212.2 2271.7 2334.6 2401.0 2468.2 F
Code Plans Chart
The first digit indicates Chart A Group Number Source for the A tone. The second digit indicates Chart
A Group Number Source for B tone.
Code MSD Digit of 3 Digit Capcode
Plan
0 1 2 3 4 5 6 7 8 9
Gen Enc 42 11 22 12 44 55 21 45 54 24
Gen Enc
Modified 42 11 22 33 44 55 66 DD EE FF
B N/A 11 22 33 12 13 21 31 23 32
C N/A 11 22 12 44 14 21 41 24 42
D N/A 11 22 12 15 55 21 51 25 52
E N/A 11 22 12 21 16 66 61 26 62
