Settings
Settings
You can make detailed settings for the network.
To change the network environment, perform “Quick Setup”. (For details
on the operations, see the separate “Quick Setup Guide”.)
• If you are using a broadband router (DHCP function), there is no need
to make the settings at “IP Address” and “Proxy”, since the DHCP
function is set to “On” in this unit’s default settings.
• Only set “Settings” when connecting to a network without a DHCP
function.
2 When making wired connection
n DHCP
Selects how to connect to the network.
On (Default) : Configure the network settings automatically from your
router.
Off : Configure the network settings manually.
n IP Address
Set the IP address within the ranges shown below.
• The Network Audio function cannot be used if other IP addresses
are set.
CLASS A: 10.0.0.1 – 10.255.255.254
CLASS B: 172.16.0.1 – 172.31.255.254
CLASS C: 192.168.0.1 – 192.168.255.254
n Subnet Mask
When connecting an xDSL modem or connector adapter directly to this
unit, input the subnet mask indicated in the documentation supplied by
your provider. Normally input 255.255.255.0.
n Gateway
When connected to a gateway (router), input its IP address.
n Primary DNS, Secondary DNS
If there is only one DNS address indicated in the documentation
supplied by your provider, input it at “Primary DNS”. If two or more
DNS are provided by your provider, enter both “Primary DNS” and
“Secondary DNS”.
n Proxy
Make this setting when connecting to the Internet via a proxy server.
Make the proxy settings only when you connect to the Internet via
a proxy server that is on your internal network or provided by your
provider, etc.
Proxy (Off) or Proxy (On) : Set the proxy server.
Proxy (Address) or Proxy (Name) : Select when inputting by address
or domain name.
Address or Name : Inputting address or domain name. Up to 38
characters can be input.
Port : Enter port number.
%
• If you cannot connect to the Internet, recheck “Connecting to a home
network (LAN)” (vpage 24).
• If you do not understand about Internet connection, contact your ISP (Internet
Service Provider) or the store from which you purchased your computer.
