Skutch Electronics BA-1000 V2.90 - Manual (Page 16)

Version 2.90 Page 16
- No Dial Tone -
After 6 seconds, the system will repeat the
process until it gets dial tone, then it will dial the
entry. After the system finishes the call, the system
will release the line and display the result for one
second, as follows:
0-Entry> 00000 C
----- Lead -----
Pause During Dialing
While the system is showing the result, see
above, you can press the # button to pause the
dialing process and the display will show the
following:
Paused-Continue?
1=Yes 3=No
You can leave the system like this until you are
ready to continue dialing, then just press 1 and the
system will pick up where it left off; or you can
press 3 or Escape to return to the MENU.
• End Of Session
When the system reaches the end of all the
dialing, it will return to the MENU.
• 15 Minute Busy Redials
When busy numbers are encountered, the
system will log them into a busy re-dial table and,
after 15 minutes, call them at the next opportunity.
If the system cannot get through to a busy number
after 8 consecutive tries, it will remove the entry
from the busy re-dial table.
• Volume Control
The volume on the BA-1000 can be increased
by multiple pressing/releasing of the 9 button. You
can decrease the volume by multiple
pressing/releasing of the 7 button. At min volume,
the speaker is completely off and trying to go lower
does nothing. At max volume, trying to go higher
does nothing. The volume control only adjusts the
volume you hear over the speaker, not what the
called party hears, and it only adjusts the volume for
Dial File and Order Taking modes. NOTE: This
volume can only be adjusted while the system is:
waiting for an answer, playing the message or
listening/recording user input, during a dial
session.
4 Select File
This mode is used to select the dialing file to
use/edit and to enter the default area code and other
local area codes. To enter this mode press Escape,
<PAUSE>, 4, #.
• Dial File Select
You can select a different file for number
entry/editing by pressing Escape, <PAUSE>, 4, #;
the display will show the following:
Current File = 0
#=Next 0-9 or *
Now you can change the dialing file, by
entering a number from 0 to 9 followed by #. The
default dialing file is 0. If you press *, you will
select the DO NOT DIAL file, and the display will
show an N for the file number in the top right; if you
select this file, you can edit/add/delete it, but you
will not be allowed to enter a dialing session with it.
You can exit by pressing Escape or continue by
pressing #.
• Area Code Entry
You must enter your local area code by
pressing Escape, <PAUSE>, 4, #, #; the display will
show the following:
Enter Local Area
Code, # =
You MUST enter the area code the system will
be calling from, then #. You can enter * then # to
remove an area code.
