Version 2.90 Page 31
If after the following steps, you are still having
problems, go to the Customer Support section.
• Reset System Setup
You can reset the system to the Factory defaults
by entering the following string:
Escape, <PAUSE>, *, #, #,
#, <PAUSE>, 1, 1
When the display shows the following, you can
press Escape to return to the MENU.
SETUP Load/Save
1=Change #=Next
Disconnect methods
Once the unit detects an answer condition, it
activates the announcement portion of the system.
The announcement will play until it detects a
Disconnect condition. The following are the
disconnect systems incorporated into the BA-1000.
The failure to detect a dialed digit within 5
seconds of a Consent code when in Play mode.
CPC disconnect. The unit will disconnect upon
the detection of a CPC pulse that is detected over the
phone line. The CPC pulse is generated by the
telephone company and is not available in all areas.
This is the ONLY form of disconnect that will give
immediate disconnect once the called party hangs
up.
The reception of 5 seconds of steady dial tone
during an incoming response period.
The detection of a pre-determined amount of no
response periods.
The detection of continuous speech for the
length of time set by the Voice Limit parameter in
the System Setup mode.
Disconnect problems
If the system is failing to disconnect when the
called party is hanging up, you can use either the
Tone Consent feature, or the No Response Hang
Up feature to solve your problem. See 8 – Out
Messages for detailed information on how to design
your announcement.
• Customer Support
All operation or technical questions should be
directed to the Customer Support Center at 916-
786-6186, between 7:30 a.m and 4:30 p.m., Pacific
time.
Before calling the Customer Support Center,
we request that you have your system set up and
within arm’s reach of the telephone. This is
essential for accurate diagnosis of the problem. If
the Customer Support Center determines that the
unit must be sent in for repair, the following
procedures MUST be followed.
• Warranty Repair
1) You MUST call the Customer Support Center
to report the problem the unit is experiencing
and to provide us with the return shipping
information and day time phone number.
2) Package the unit in the original box and packing
material. If you do not ship your unit with the
original packaging material you WILL be
charged for the replacement of this material.
3) You are responsible for all shipping costs to the
Customer Support Center.
4) The Customer Support Center will pay for
UPS Ground shipping back to the customer
ONLY during the first year of the warranty
period, and only if the destination is within the
USA. If the customer chooses any other form of
shipment, or is located outside of the USA, the
customer will incur all shipping charges.
• Non-Warranty Repair
If your unit should require Non-warranty
service, follow these procedures:
1) Follow the WARRANTY REPAIRS procedures.
2) The customer will pay 100% of all shipping
charges to and from the Customer Support
Center.
3) The customer will be charged for the following:
A flat rate labor charge.
All parts replaced.
Shipping charges
4) All repairs must be prepaid with Visa, Master
Card, American Express, Cashiers Check or
Money Order.
• Service Warranty
The Customer Support Center warrants all
repairs for a period of 90 days from the date of the
service invoice.
