Version 2.90 Page 2
Quick Start Sheet
This section is designed to get the system “On
Line” fast! You will also find it helpful if you ever
need to have someone else operate your system for
you. Anyone should be able to get the system “On
Line” and calling people, without help, if they
follow these simple steps.
• Term Definitions
<PAUSE> = wait 2 seconds
• Initial Setup
1) Plug power adapter to 110VAC and into the BA-
1000 and wait until it shows the following:
0-Menu-Ver 2.9-A
–Press a Number-
2) Enter: 4, # and it will show the following:
Current File = 0
#=Next 0-9 or *
3) Enter: #, <PAUSE>, *, #, <PAUSE>.
4) Now enter the default (local) area code the
system will be calling FROM, then #.
• Record An Announce
ONLY Message
To record a basic message, where you don’t
want any information from the people you are
calling, do the following:
1) Press Escape and wait until it shows the
following:
0-Menu-Ver 2.9-A
–Press a Number-
2) Enter: 8, #, <PAUSE>, 1.
3) Have your message ready and insert the
Microphone when it shows the following:
Mic in & Press 1
4) Press 1 and start saying your message.
5) When you are done talking, press Escape and it
will show the following:
Get Response
0-9 or * #=Next
6) Enter: 9 then #; the system will now play your
message back and return to MENU.
• Record A One Question
Message
To record a basic message and ask for some
information at the end, do the following:
1) Press Escape and wait until it shows the
following:
0-Menu-Ver 2.9-A
–Press a Number-
2) Enter: 8, #, <PAUSE>, 1.
3) Have your message ready and insert the
Microphone when it shows the following:
Mic in & Press 1
4) Now press 1 and immediately start saying your
message.
5) When you are done talking, press Escape and it
will show the following:
Get Response
0-9 or * #=Next
6) Enter: * then #; the system will now play your
message back and return to MENU.
• Dial A Range of Numbers
1) Press Escape and wait until it shows the
following:
0-Menu-Ver 2.9-A
–Press a Number-
2) Enter: 2 then # and it will show the following:
1=NEW from Start
3=Add to End
