Skutch Electronics BA-1000 V2.90 - Manual (Page 25)

Version 2.90 Page 25
Set the Current Time
Now the display will show:
Enter 24 hr Time
- # = 00:00:00 –
The current time will appear in the bottom of
the display. You can enter a new time (in 24 hour
format) followed by #, or just press # to keep the
current time.
• Set The Dial Times
This option allows you to set the starting and
stopping dialing times for each day of the week; the
display will look as follows:
Set DIALING Time
1=Change #=Next
You can press 1 to change the dialing times or #
to proceed to the next option. You can press Escape
to exit setup mode.
Select The Day To Change
Press 1 to change the time; the display shows:
Enter day, 1 – 7
#=Sunday
To change the dialing times for a day, press the
corresponding number followed #; i.e. 1 for Sunday,
2 for Monday, etc.
Set The Start Time
Now the display will show:
Enter START Time
- # = 09:00 –
Now you can enter a new start time (in 24 hour
format) followed by #, or just press # to keep the
current time. You cannot enter a time earlier than
9:00 a.m.
Set The Stop Time
Now the display will show:
Enter STOP Time
- # = 21:00 –
Now you can enter a new stop time (in 24 hour
format) followed by #, or just press # to keep the
current time. You cannot enter a time later than 9:00
p.m. Now the system will return you to the initial
dialing times screen so you can select another day to
adjust. To exit from this mode, press Escape from
the initial dialing times screen.
• Load/Save Defaults
This option allows you to reset the system back
to factory defaults, save the defaults in a file on the
ZIP disk or load the defaults from a file on the ZIP
disk. The display will look as follows:
SETUP Load/Save
1=Change #=Next
You can press 1 to load/save the defaults or # to
proceed to the next option.
Factory Defaults
The display will now show:
1=Factory Reset
3=Load/Save File
Pressing 1 will make the system reset the
defaults to the factory programmed values and show
the following for 2 seconds:
Loading Defaults
- Please Wait –
The system will then return you to the initial
load/save screen.
Load/Save To File
Pressing 3 will allow the system load/save the
system setup parameters in a file on the ZIP disk; the
display will show the following:
1=Load from Disk
3=Save to Disk
