Version 2.90 Page 30
Press 1 to change the string, then enter the new
string followed by #; press # to go to the next option.
You can press Escape to exit setup mode.
• Total Calls
This entry shows the master total phone calls
the system has processed. This can only be reset at
the factory. The display will look as follows:
- Total Calls -
----00000000----
You can press # or Escape to return to MENU.
Appendix
•
24 hour time format
The system uses 24 hour time format for the
internal clock.
! 12:00 a.m. = 00:00
! 1:00 a.m. = 01:00
! 2:00 a.m. = 02:00
! 3:00 a.m. = 03:00
! 4:00 a.m. = 04:00
! 5:00 a.m. = 05:00
! 6:00 a.m. = 06:00
! 7:00 a.m. = 07:00
! 8:00 a.m. = 08:00
! 9:00 a.m. = 09:00
! 10:00 a.m. = 10:00
! 11:00 a.m. = 11:00
! 12:00 p.m. = 12:00
! 1:00 p.m. = 13:00
! 2:00 p.m. = 14:00
! 3:00 p.m. = 15:00
! 4:00 p.m. = 16:00
! 5:00 p.m. = 17:00
! 6:00 p.m. = 18:00
! 7:00 p.m. = 19:00
! 8:00 p.m. = 20:00
! 9:00 p.m. = 21:00
! 10:00 p.m. = 22:00
! 11:00 p.m. = 23:00
•
Dialing Status Codes
The following are the dialing status codes the
system displays in the top right during dialing and
editing:
! N = New number, never dialed.
L = Lead, a qualified lead response detected.
B = Busy number.
R = Recorded Message, operator recorded message.
U = Unanswered call.
A = Answering Machine.
F = Fax Machine.
H = Hang Up detected.
D = Do Not Dial, set for no dial.
C = Chained, this entry chained to the next one.
x = Delete, this # will be deleted on exiting Edit
Number mode.
• Special Entry Codes
The following are the special entry codes you
can put in the Pre-Dial String and in entries that
you want to chain to a phone number:
*00 – Dial the next touch tone digit for 5 seconds.
*01 to 09 – Pause for 1 to 9 seconds.
*1 – Wait for return dial tone.
*2 – Wait for 5 seconds of silence.
*3 – Dial a touch tone *.
*4 – Dial a touch tone #
*5 – Dial the rest of the phone number string as
touch tones.
• Outgoing Prompt Codes
The following are the prompt codes available
for your outgoing messages:
0 = Redo This Prompt.
1 = Get Number Input.
2 = Get Poll Input.
3 = Get Branch Input.
4 = Get Audio Input.
5 = Voice Consent.
6 = Tone Consent.
7 = Remove # Input.
8 = Get Alert Input.
9 = End of Prompt.
* = Get Audio Input then End of Prompt
• Trouble shooting
This section has been provided to help the user
in case of problems. For best results, all of the
following procedures should be read and followed.
