MNR-310 System Administrator ’s Manual
76
Configure Device Settings
After adding a device to the NVR system, you may continue to configure its video, motion
detection, PTZ or preset tour settings on Setup page Devices tab. In this section, we will
guide you through how to configure these settings and their corresponding functions.
Configure Video Format
Go to Setup page Device tab, select a device from Device List , and then go to Video tab to
configure the video format of the stream output from the device. If the device is currently in
Dual Stream mode, you may switch the stream in live view window by click on the switch
below and configure individual settings for Media 1 and Media 2.
Video Settings Attributes
Field Name Description
TV Standard Default is NTSC .
Stream Mode * 1
Select one of the streaming modes this device supports.
Mounting Type * 2
Select the mounting position.
Installation Angle * 3
Input the angle for a device mounted on the wall.
Video encoder Select the desired codec.
Resolution Select the desired resolution.
Video Quality * 4
Select the desired video quality.
Frame Rate(fps) Select the desired frame rate.
Maximum Bitrate This puts a hard cap on the maximum bit rate allowed in any given
second of streaming. Assigning a limited bit rate may cause a few
dropped frames when the stream data overflows the allowed bit rate.
Bitrate * 5 This is the target bitrate that the camera will attempt to provide when
