MNR-310 System Administrator ’s Manual
83
4. When the setting is finished, click “ Apply ” to save, and then “ Close ” to exit this page. To
check or modify the regions you set, please go through clicking “ Get Motion Settings ”,
Motion Setup ” and then “ Motion Enable ” buttons, the saved regions are already selected
on the list, select one to proceed.
Adjustment Attributes
Field Name Description
Sensitivity(1-100) Determines how sensitive the camera reacts to the movement. The higher
the sensitivity level is, the smaller motion will trigger the alarm, but may give
false alarms. Default is 70.
Timer(0-300 secs) The interval before the next motion detection can be triggered again. Default
is 1 second.
Threshold (%) The threshold level of this motion detection region. The lower threshold level
is, smaller portion of the region would be considered as motions, which is
more easily to be triggered, but may give more false alarms.
Note
1. If you have changed the motion detection settings via the web configurator, please remember
to come back to NVR and press “ Get Device Settings ”, then “ Apply ” to save to NVR. This is
to ensure that the settings in NVR are always in sync with the device.
2. If a motion region is set, once a movement is detected in this region, in live view:
(1) the red region frame will blink, and (2) a new alert entry will be generated in the event list.
3. PIR detection is available only for models with this function.
