Midplane board removal
Before doing this task, do the following:
•
Remove the top cover.
•
Unfasten/disconnect cables.
•
Remove the rear panel.
•
Remove the carrier board.
To remove the midplane board proceed as illustrated.
Related Topics
Installing components and dressing cables
on page 102
Drive cable assembly removal
Before doing this task, do the following:
•
Remove the top cover.
•
Unfasten/disconnect cables.
•
Remove the rear panel.
•
Remove the carrier board.
06 November 2012
K2 Solo 3G Service Manual
101
Removing and replacing FRUs
