3. For the Control Team and the loopback, select adapter names in the “Device Name” column and
rename them as follows:
a) Select the adapter name.
b) Select
File | Rename to enter rename mode.
c) Type the name, as specified in the following table:
And rename it as follows: In the Device Name column, select this adapter name…
Control Team TEAM : Control Team
4. Do one of the following:
• If you intend to use SiteConfig for device discovery and IP address configuration, you do not
need to set an IP address for the Control Team at this time. You are done with this procedure.
• If you are not using SiteConfig, set an IP address for the Control Team at this time. Use
standard Windows procedures.
NOTE: Do not set IP addresses for the two Media Connections.
Next, proceed as follows:
• If network configuration is complete, enable the write filter.
• If continuing with network configuration, your next task is to reorder adapters.
Reorder adapters
Before beginning this task, make sure of the following:
• Adapters are named correctly according to their PCI bus location
• The control team is created
• The team and loopback are named
1. If K2 software is installed, disable the write filter, if it is not already disabled.
2. On the Windows desktop right-click My Network Places and select Properties .
The Network Connections window opens.
3. Select Advanced , then Advanced Settings…
06 November 2012 K2 Solo 3G Service Manual 53
Service procedures
