Internal Parts Removal
The sections that follow show how to remove internal parts from the K2 Solo 3G system.
CAUTION: To avoid possible damage to circuit boards and other sensitive parts, turn off the
K2 Solo 3G system and disconnect both power cords before opening the top cover or removing
any internal parts.
Top cover removal
Before doing this task, do the following:
•
Remove the front bezel.
•
Remove the fan assembly.
•
Remove the disk controller board.
06 November 2012
K2 Solo 3G Service Manual
95
Removing and replacing FRUs
