Status bar
System status messages appear in the AppCenter status bar, which is located across the bottom of
the AppCenter window, and consists of a message area, several tool buttons, and a status icon. The
button icons appear only when the related function is active. In the position of the StatusPane button,
status icons appear.
The status bar displays information about the state of the delegated channel as well as low-level
error messages. (High priority error messages are displayed in pop-up windows.)
If you select a channel, a status message appears on the left-hand side of the status bar. If a potential
error arises while an application is running in a channel, a status message flashes briefly on the
left-hand side of the status bar, and an icon displays on the right-hand side. Double click on the icon
to open the status pane to view a more detailed message about the channel’s status.
The status icon changes depending on the status of the current status message.
Description Name Icon
A recent information message is present. Information
There is at least one warning message, and no alert messages. Warning
There is at least one uncleared alert message. Alert
Status pane
Current and previous system status messages can be viewed in the StatusPane. The system status
pane also displays general information such as the video and audio settings on the channels. To open
the StatusPane, click
Help | System Status .
40 K2 Solo 3G Service Manual 06 November 2012
System Messages
