4. Setup and Maintenance
4 – 4 Operating Instructions – Rev. 1 / 7.2002
4.3 RUNNING PANEL TESTS
There are four panel tests:
D
Test 1: Button/Lamp, Fader and Digipots
D
Test 2: Display, Beep and Lowhigh
D
Test 3: OnAir Highlight
D
Test 4: Mainframe Connection
4.3.1 STARTING THE TEST
To start the panel tests use the button in the Mattes panel section or in the Aux
panel section
Mattes
Hue/
Softness
Chroma/
Position
Luminance/
Angle
Matte
1
Matte
2
flat
wash
Wiper
Text
Illegal
0 1 2 3 4 5 6 7
Mode
H
lock
Ctr
V
lock
Positioner
0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5
Menu
Deleg
flat
wash
Wiper
Text
Matte
1
+
+
+
+
+
+
+
+
= Test 1
= Test 2
= Test 3
= Test 4
Mattes Panel
Exit Test mode by pressing the same button again that you have pressed when you
entered the current test mode.
