User’s Manual of GSW-1602SF / GSW-2404SF
Discarded Frames If an LLDP frame is received on a port, and the switch's internal table has run full, the LLDP
frame is counted and discarded. This situation is known as "Too Many Neighbors" in the
LLDP standard. LLDP frames require a new entry in the table when the Chassis ID or
Remote Port ID is not already contained within the table. Entries are removed from the
table when a given port links down, an LLDP shutdown frame is received, or when the entry
ages out.
TLVs Discarded Each LLDP frame can contain multiple pieces of information, known as TLVs (TLV is short
for "Type Length Value"). If a TLV is malformed, it is counted and discarded.
TLVs Unrecognized The number of well-formed TLVs, but with an unknown type value.
Org. TLVs Discarded The number of organizationally TLVs received.
AgeOuts Each LLDP frame contains information about how long time the LLDP information is valid
(age-out time). If no new LLDP frame is received within the age out time, the LLDP
information is removed, and the Age-Out counter is incremented.
Table 4-43 LLDP Statistics
4.15 Green Networking
In line with the energy-saving trend worldwide, PLANET delivers the new generation green Switch- GSW-1602SF /
GSW-2404SF Series Web Smart Gigabit Ethernet Switch. With both benefit of energy saving and gigabit performance, the
new engine that provides power saving for less energy consumption but not reduce the Gigabit performance.
The GSW-1602SF / GSW-2404SF incorporate two advanced Green Networking technologies:
„ Hibernation Link Down power saving
„ Intelligent scales power based on cable length
The Hibernation Link Down power savings goes beyond IEEE specifications to automatically lower power for a given port
when it is not linked. With the Hibernation Link Down power savings technology, the GSW-1602SF / GSW-2404SF will
automatically adjusts power usage of the ports that are shutdown or not connected to network device. The other technology
adopted, intelligent scales power, is an intelligent algorithm that actively determines the appropriate power level based on
cable length. The Green Networking screen in Figure 4-89 appears.
