Command Guide of SGS-5220-24T2X
4.2.45.78 qos map tag-cos
Command:
qos map tag-cos pcp <Pcp : 0-7> dei <Dei : 0-1> cos <Cos : 0~7> dpl <Dpl : 0~1>
qos Quality of Service
map QoS Map/Table configuration
tag-cos Map for tag to cos configuration
pcp Specify PCP (Priority Code Point)
<Pcp : 0-7> Specific PCP
dei Specify DEI (Drop Eligible Indicator)
<Dei : 0-1> Specific DEI
cos Specify class of service
<Cos : 0~7> Specific class of service or range
dpl Specify drop precedence level
<Dpl : 0~1> Specific drop precedence level or range
Default:
Disabled
Usage Guide:
To configure (PCP, DEI) to (QoS class, DP level) Mapping of QoS for specific interface
Example:
To configure (PCP, DEI) to (QoS class, DP level) Mapping of QoS as below table for GigabitEthernet X/X
Switch# configure terminal
Switch (config)# interface GigabitEthernet X/X
Switch (config-if) # qos map tag-cos pcp 4 dei 0 cos 5 dpl 1
4.2.45.79 qos pcp
Command:
qos pcp <Pcp : 0-7>
qos Quality of Service
pcp Priority Code Point configuration
<Pcp : 0-7> Specific Priority Code Point
