User’s Manual of WGSD-10020 Series
489
QoS Storm Multicast
Description:
Set or show the multicast storm rate limiter.
Syntax:
QoS Storm Multicast [enable|disable] [<packet_rate>]
Parameters:
enable : Enable multicast storm control
disable : Disable multicast storm control
<packet_rate>: Rate in fps (1, 2, 4, ..., 512, 1k, 2k, 4k, ..., 32768k)
Default Setting:
disable
Example:
Enable multicast storm control in 2fps
WGSD-10020HP:/>
QoS Storm multicast enable 2
QoS QCL Add
Description:
Add or modify QoS Control Entry (QCE).
If the QCE ID parameter <qce_id> is specified and an entry with this QCE ID already exists, the QCE will be modified.
Otherwise, a new QCE will be added. If the QCE ID is not specified, the next available QCE ID will be used. If the next
QCE ID parameter <qce_id_next> is specified, the QCE will be placed before this QCE in the list. If the next QCE ID is not
specified and if it is a new entry added, the QCE will be placed last in the list. Otherwise if the next QCE ID is not specified
and if existing QCE is modified, QCE will be in the same location in the list. To modify and move the entry to last in the list,
use the word 'last' for <qce_id_next>.
Syntax:
QoS QCL Add [<qce_id>] [<qce_id_next>] [<port_list>] [<tag>] [<vid>] [<pcp>] [<dei>] [<smac>] [<dmac_type>] [(etype
[<etype>]) | (LLC [<DSAP>] [<SSAP>] [<control>]) | (SNAP [<PID>]) | (ipv4 [<protocol>] [<sip>] [<dscp>] [<fragment>]
[<sport>] [<dport>]) | (ipv6 [<protocol>] [<sip_v6>] [<dscp>] [<sport>] [<dport>])] [<class>] [<dp>] [<classified_dscp>]
Parameters:
<qce_id> : QCE ID (1-256), default: Next available ID
