User’s Manual of IGS-10020PT / IGS-10020HPT
24
1. INTRODUCTION
PLANET IGS-10020PT / IGS-10020HPT Industrial 8-Port 10/100/1000T 802.3af/at PoE + 2-Port 100/1000X SFP Managed
Switch (-40~75 degrees C) is a managed switch with multiple Gigabit copper ports plus two Gigabit SFP mini-GBIC slots with
connective ability and robust layer 2 features. The description of IGS-10020PT / IGS-10020HPT is shown as below:
IGS-10020PT Industrial 8-Port 10/100/1000T 802.3af PoE + 2 100/1000X SFP Managed Switch (-40~75 degrees C)
IGS-10020HPT Industrial 8-Port 10/100/1000T 802.3at PoE + 2 100/1000X SFP Managed Switch (-40~75 degrees C)
“Industrial Managed Switch” mentioned in this Quick Installation Guide represents the above two models.
1.1 Packet Contents
Open the box of the Industrial Managed Switch and carefully unpack it. The box should contain the following items:
 Industrial Managed Switch x 1
 Quick Installation Guide x 1
 User’s Manual CD x 1
 DIN Rail Kit x 1
 Wall Mounting Kit x 1
 RS232 Console Cable x 1
 Dust Cap x 11
If any of these are missing or damaged, please contact your dealer immediately. If possible, retain the carton including the
original packing materials to enable you to repack the product in case there is a need to return it to us for repair.
