Module Configuration
49TPTQ-104C ♦ 48TQuantum Platform
12TUser Manual
47TIEC 60870-5-104 Client
25
NTP Request
Number of requests to NTP server
26
NTP Response
Number of responses from NTP server
27
SNTP
Computation
Number of times SNTP time computed
28
SNTP Set
Number of times SNTP time set
29
NTP Timeout
Number of NTP response timeouts
5.3.3 User-Constructed Command Block (9901)
Block identification code 9901 is used to issue one or more user-constructed
commands. When the module receives a block 9901 identification code, it will
place the included commands into the command queue.
Block Format from Processor (4x Register Data) to module
Word Offset in Block
Data Field(s)
Description
0
Sequence
Counter
This field contains a new value each time the user
wishes to request a new command block.
1
Block ID
This field contains the block identification code of
9901 for the block.
2
Command Count This field defines the number of user commands
contained in the block. The valid range for the field is
1 to 10.
3 to 8
Command #1
Data required to build the user defined command in
the command queue.
9 to 14
Command #2
Data required to build the user defined command in
the command queue.
15 to 20
Command #3
Data required to build the user defined command in
the command queue.
21 to 26
Command #4
Data required to build the user defined command in
the command queue.
27 to 32
Command #5
Data required to build the user defined command in
the command queue.
33 to 38
Command #6
Data required to build the user defined command in
the command queue.
39 to 44
Command #7
Data required to build the user defined command in
the command queue.
45 to 50
Command #8
Data required to build the user defined command in
the command queue.
51 to 56
Command #9
Data required to build the user defined command in
the command queue.
57 to 62
Command #10
Data required to build the user defined command in
the command queue.
63
Spare
Not used.
