Playback sound cannot be heard or is quiet
• When playing data from an SD card, confirm that is lit green.
• Raise the faders on the playback channels, and confirm that the level meters are lit.
The sounds of devices connected to input jacks are distorted
• Confirm that are not lighting red. If one is lighting, lower its input gain. can also be turned on.
• Confirm that level meters are not lighting to their highest levels. If a level meter is lighting to its highest
level, lower its fader.
A send effect is not working
• Confirm that the EFX RTN is unlit.
• Raise the EFX RTN fader, and confirm that the EFX RTN level meters are lit.
• Check the send amounts of channels that are to have effects used on them.
There is no sound or output is very quiet from MONITOR OUT A–C
• Confirm the mixes of each output.
• Confirm that the output volume of each output is raised (MONITOR OUT A–C knobs).
• Check the MONITOR OUT A–C switch settings.
Audio files cannot be assigned to SOUND PAD buttons or tracks
• Check the format of the audio file to be assigned. ( → “Assigning audio files to SOUND PAD buttons”
on page 53, → “Assigning audio files to tracks” on page 74 )
• If the audio file is stored on an SD card, store it outside the PROJECT folder.
EQ, built-in effect or audio interface functions cannot be used
• Confirm that the sampling rate is set to 44.1 kHz or 48 kHz.
SOUND PAD functions cannot be used
• Confirm that INPUT SEL is set to SOUND PAD.
• Confirm that the level meters for channels 7 and 8 are lit.
• Confirm that files are assigned.
• Confirm that the sampling rate is set to 44.1 kHz or 48 kHz.
108
