Zoom LiveTrak L-8 Portable 8-Channel Digital Mixer and Multitrack Recorder - Manual (Page 26)

4.
Connect instruments, mics, speakers and other equipment.
HINT
Equipment connection examples ( → “Equipment connection examples” on page 21 )
5.
Set to ON.
6.
Turn on the output devices connected to the .
NOTE
• When using a passive guitar or bass guitar, connect it to channel 1 or 2, and turn on. ( → “Top” on page 5 )
• When using a condenser mic, turn on. ( → “Top” on page 5 )
• The power will automatically turn off if the is unused for 10 hours. To keep the power on at all times, dis-
able the automatic power saving function. ( → “Disabling the automatic power saving function” on page 98 )
Turning the power off
1.
Minimize the volume of output devices connected to the .
2.
Turn off the power of output devices connected to the .
3.
Set to OFF.
The following screen appears and the power turns off.
NOTE
When the power is turned off, the current mixer settings are saved in the project on the SD card. If they cannot
be saved to the SD card, they will be saved in the
.
26
