Zoom LiveTrak L-8 Portable 8-Channel Digital Mixer and Multitrack Recorder - Manual (Page 34)

NOTE
• The can store 7 scenes.
• If a button that already has a scene saved is selected, that scene will be overwritten.
• The following items are saved with scenes.
– Fader positions (each channel, EFX 1/2 RTN and MASTER)
– MUTE ON/OFF (each channel, EFX 1/2 RTN and MASTER)
– LOW CUT
– EQ HIGH
– EQ MID
– EQ LOW
– SEND EFX
– PAN
– EFX TYPE
– EFX parameters
– INPUT SEL settings
Recalling scenes
1.
Press so that it lights.
This opens the SCENE screen.
2.
Press the button (SCENE 1–7) for the scene to recall.
3.
Turn to select RECALL, and press .
To not recall the scene, turn , select CANCEL, and press .
NOTE
• If the actual channel fader position differs from the channel fader position shown, the volume will not change
until the fader is moved to the same position. ( → “Input channel section” on page 5 )
• “Empty” will appear at the bottom right of the display if the scene has not been saved.
34
