Zoom LiveTrak L-8 Portable 8-Channel Digital Mixer and Multitrack Recorder - Manual (Page 110)

Specifications
Number of
input and output
channels
Inputs MIC/LINE 6
LINE 2
Output MASTER OUT 1
MASTER OUT (PHONES) 1
MONITOR OUT (PHONES) 3
Inputs MIC/LINE Type XLR/TRS combo jacks (XLR: 2 HOT, TRS: TIP HOT)
Input gain +10 – +54 dB/–3 – +41 dB (when Hi-Z ON)
Input impedance XLR: 3 kΩ
TRS: 3 kΩ/1 MΩ (when Hi-Z ON)
Maximum input level –2 dBu when –26dB switch OFF (at 0 dBFS)
+24 dBu when –26dB switch ON (at 0 dBFS)
Phantom power +48 V
LINE Type TS phone jack
Input impedance 10 kΩ
Maximum input level +3 dBu
Smartphone
connection jack
Type TRRS mini jack (4-contact/TIP: L, RING 1: R, RING 2: GND, SLEEVE: MIC)
Input impedance 10 kΩ
Maximum input level +3 dBu
Output MASTER OUT Type XLR jacks (balanced)
Maximum output level +14.5 dBu
Output impedance 100 Ω
MASTER OUT
(PHONES)
Type Standard stereo phone jack
Maximum output level 10 mW + 10 mW (60Ω load)
Output impedance 10 Ω
MONITOR OUT
(PHONES)
Type Standard stereo phone jack
Maximum output level 10 mW + 10 mW (60Ω load)
Output impedance 10 Ω
Buses MASTER 1
MONITOR 3
SEND EFX 1
Channel strip LOW CUT 75 Hz, 12 dB/OCT
EQ HIGH: 10 kHz, ±15 dB, shelving
MID: 2.5 kHz, ±15 dB, peaking
LOW: 100 Hz, ±15 dB, shelving
Level meter 9 segments
Send effects 8 types
Recorder Maximum simultaneous
recording tracks
12 at 44.1/48/96 kHz
Maximum simultaneous
playback tracks
10
Recording format WAV 44.1/48/96 kHz, 16/24-bit, mono/stereo
Recording media 4GB–32GB SDHC-compliant cards (Class 10 or higher)
64GB–512GB SDXC-compliant cards (Class 10 or higher)
Audio interface 44.1/48 kHz Recording: 12 channels Playback: 4 channels
Bit depth 24-bit
Interface USB 2.0
Card reader Class Mass storage USB 2.0 High Speed
Sampling frequency 44.1/48/96 kHz
Frequency response 20 Hz – 20 kHz: –1 dB at 44.1 kHz
20 Hz – 40 kHz: –3 dB at 96 kHz (when GAIN at 3 o'clock)
Equivalent input noise –121 dBu or less (IHF-A) at +54dB/150Ω input
Display LCD with backlight (96×64 resolution)
Power 4 AA batteries (alkaline, lithium, or rechargeable NiMH)
AC adapter (ZOOM AD-17): DC 5V/1A
Supports USB bus power
Estimated continuous recording time using batteries Recording 44.1kHz/16-bit/4ch audio to SD card (when 48V is OFF, LCD BACKLIGHT
is 15sec, BATTERY SAVING is ON and headphone impedance is 62Ω):
Alkaline batteries: about 2 hours
NiMH batteries (1900 mAh): about 3.5 hours
Lithium batteries: about 6.5 hours
• The above values are approximate.
• Continuous battery operation times were determined using in-house testing
methods. They will vary greatly according to use conditions.
Power consumption 5 W
External dimensions 268 mm (W) × 282 mm (D) × 74 mm (H)
Weight (main unit only) 1.56 kg
110
