Zoom LiveTrak L-8 Portable 8-Channel Digital Mixer and Multitrack Recorder - Manual (Page 11)

⑤ MONITOR OUT knobs A–C
Use to adjust the volumes of the signals output from the MONITOR OUT PHONES A–C jacks.
⑥ MONITOR OUT A–C switches
These switch the signals output from the MONITOR OUT PHONES A–C jacks.
Status Explanation
MASTER The same signals as those output from the MASTER OUT jacks are output.
MIX A–C Signals set in MIXER mode are output.
⑦ MASTER REC/PLAY button
Use this button to switch between recording the signal input on the master bus to the SD card and playing back
an already recorded file from the SD card.
Status Explanation
Lit red The signal will be recorded to the SD card after adjustment by the master fader.
Lit green
The playback signal of a file is inserted on the master bus. The REC/PLAY buttons of
other channels will become unlit at this time.
Unlit Files will neither be recorded nor played back.
⑧ MASTER MUTE button
This mutes or unmutes the MASTER OUT jacks. To mute the signal, press this button to light it.
⑨ Master level meters
These show the signal levels output from the MASTER OUT jacks in a range from −48 dB to 0 dB.
⑩ Master fader
This adjusts the signal levels output from the MASTER OUT jacks in a range from −∞ to +10 dB.
NOTE
If the actual master fader position differs from the master fader position recalled using the scene function, for
example, the level meter will show the recalled fader position. To enable fader operation, move the fader to the
position shown by the level meter.
When AUTO REC is activated, however, the master fader position will not be shown.
11
