█ EFFECT mode
① Effect type buttons
① Effect type buttons
The currently selected effect type appears lit.
Press a button to change the effect. The selected effect will be shown on the display. Its parameters can be
changed using the Selection encoder.
(
→ “Send effect specifications” on page 111 )
⑤
①
②
③
④
No. Item Explanation
① Effect type This shows the selected effect type.
② Parameter This shows the name of an adjustable effect parameter.
③ Parameter knob
This shows a parameter knob.
The knob position shows the parameter setting value.
④ Parameter setting value
This shows the parameter setting value.
It appears highlighted when selected.
⑤
Remaining battery charge
(when battery-powered)
This shows the remaining battery charge. When the remaining battery charge
becomes low, replace the batteries or connect an AC adapter.
15
