Setting signals output from MONITOR OUT A–C
The MONITOR OUT A–C jacks can be set to output the same mix as the MASTER OUT or different mixes.
MASTER and MIX A–C buttons
Display
Selection encoder
MIXER mode button
MONITOR OUT switches
MONITOR OUT knobs
MIX COPY button
MIX PASTE button
Adjusting the MONITOR OUT A–C mixes
1.
Press so that it lights.
This opens the MIXER screen.
2.
Press a – button to select the output to mix.
The selected output button lights and operation of all the channel faders is enabled.
NOTE
The level meters show the fader positions. If the actual channel fader position differs from the channel fader
position shown, the volume will not change until the fader is moved to the same position.
HINT
The can also be turned to select MIX A, MIX B or MIX C.
3.
Use the channel and EFX RTN faders to adjust the volumes.
Channel and EFX RTN faders
