Settings List
The tables below list all of the settings/functions that can be adjusted from the CN35 digital piano’s panel interface,
in addition to available ranges/types, default settings, and Registration/Startup Setting storing capabilities.
No. Setting Name Range / Type Default Setting Registration Startup Setting
1. Basic Settings
1-1 Tone Control Off, Brilliance, Loudness, Bass Boost, Treble Boost, Mid Cut, User Off z z
Brilliance –10 - +10 0 z z
User Low –6 dB - +6dB 0 dB z z
User Mid Low –6 dB - +6dB 0 dB z z
User Mid High –6 dB - +6dB 0 dB z z
User High –6 dB - +6dB 0 dB z z
1-2 Speaker Volume Normal, Low Normal - z
1-3 Phones Volume Normal, High Normal - z
1-4 Line Out Volume 0 - 10 10 - z
1-5 Audio Rec. Gain 0 dB - +15 dB 0 dB - z
1-6 Tuning 427.0Hz - 453.0 Hz 440.0 Hz z z
1-7 Damper Hold Off, On Off z z
1-8 Four Hands Off, On Off z z
1-9 Startup Setting - - - -
1-10 Factory Reset - - - -
2. Virtual Technician
2-1 Voicing Normal, Mellow 1, Mellow 2, Dynamic, Bright 1, Bright 2 Normal z z
2-2 Damper Resonance Off, 1 - 10 5 z z
2-3 Damper Noise Off, 1 - 10 5 z z
2-4 String Resonance Off, 1 - 10 5 z z
2-5 Key-off Effect Off, 1 - 10 5 z z
2-6 Fall-back Noise Off, 1 - 10 5 z z
2-7 Hammer Delay Off, 1 - 10 5 z z
2-8 Topboard Open3, Open2, Open1, Closed Open 3 z z
2-9 Decay Time 1 - 10 5 z z
2-10 Minimum Touch 1 - 20 1 z z
2-11 Temperament Equal z z
Stretch Tuning Off, On, Piano Only Piano Only z z
Stretch Curve Normal, Wide, User1, User2, User3, User4 Normal z z
User Tuning –50 - +50 0 z z
Temperament Key
Equal, Pure Major, Pure Minor, Pythagorean, Meantime,
Werckmeister, Kirnberger, User
C z z
User Temperament –50 - +50 - z z
2-12 User Key Volume Off, User1, User2, User3, User4 Off z z
User Key Volume value –50 - +50 0 z z
2-13 Half-Pedal Adjust 1 - 10 5 z z
2-14 Soft Pedal Depth 1 - 10 5 z z
3. Key Settings
3-1 Lower Octave Shift 0 - +3 0 z z
3-2 Lower Pedal On/Off Off, On Off z z
3-3 Layer Octave Shift -2 - +2 0 z z
3-4 Layer Dynamics Off, 1 - 10 10 z z
