8
•
The minimum TTL value required for a multicast packet to be forwarded
•
The maximum number of downstream nodes for a single multicast forwarding table entry
•
The maximum number of entries in the multicast forwarding table
Configuring Multicast Static Routes
By configuring a multicast static route for a given multicast source, you can specify an RPF interface or an
RPF neighbor for multicast traffic from that source.
Follow these steps to configure a multicast static route:
To do...
Use the command...
Remarks
Enter system view
system-view
—
Configure a multicast
static route
ip rpf-route-static source-address { mask |
mask-length } [ protocol [ process-id ] ]
[ route-policy policy-name ] { rpf-nbr-address |
interface-type interface-number } [ preference
preference ] [ order order-number ]
Required
No multicast static route
configured by default.
Delete multicast static
routes
delete ip rpf-route-static
Optional
CAUTION:
When configuring a multicast static route, you cannot specify an RPF neighbor by providing the type and
number (
interface-type interface-number) of the interface connecting the RPF neighbor if the interface type
of the RPF neighbor is Ethernet, Layer 3 aggregate, Loopback, RPR, or VLAN-interface; instead, you can
specify such an RPF neighbor only by its address (
rpf-nbr-address).
Configuring a Multicast Routing Policy
You can configure the router to determine the RPF route based on the longest match principle. For more
information about RPF route selection, refer to
.
By configuring per-source or per-source-and-group load splitting, you can optimize the traffic delivery
when multiple data flows are handled.
Follow these steps to configure a multicast routing policy on the public network:
To do...
Use the command...
Remarks
Enter system view
system-view
—
Configure the device to select the
RPF route based on the longest
match
multicast longest-match
Required
The route with the highest priority is
selected as the RPF route by default
Configure multicast load splitting
multicast load-splitting
{ source | source-group }
Optional
Disabled by default
