7
Address Description
224.0.0.2 All multicast routers on this subnet
224.0.0.3 Unassigned
224.0.0.4 Distance Vector Multicast Routing Protocol (DVMRP) routers
224.0.0.5 Open Shortest Path First (OSPF) routers
224.0.0.6 OSPF designated routers/backup designated routers
224.0.0.7 Shared Tree (ST) routers
224.0.0.8 ST hosts
224.0.0.9 Routing Information Protocol version 2 (RIPv2) routers
224.0.0.11 Mobile agents
224.0.0.12 Dynamic Host Configuration Protocol (DHCP) server/relay agent
224.0.0.13 All Protocol Independent Multicast (PIM) routers
224.0.0.14 Resource Reservation Protocol (RSVP) encapsulation
224.0.0.15 All Core-Based Tree (CBT) routers
224.0.0.16 Designated Subnetwork Bandwidth Management (SBM)
224.0.0.17 All SBMs
224.0.0.18 Virtual Router Redundancy Protocol (VRRP)
2. IPv6 multicast addresses
Figure 4 IPv6 multicast format
Referring to
Figure 4 , the meanings of the fields of an IPv6 multicast address are as follows:
• 0xFF: The most significant 8 bits are 11111111, indicating that this address is an IPv6 multicast
address.
Figure 5 Format of the Flags field
• Flags: Referring to Figure 5 , the following table describes the four bits of the Flags field.
Table 4 Description on the bits of the Flags field
Bit Description
0 Reserved, set to 0
