28
Downstream interface(s) information:
Total number of downstreams: 1
1: GigabitEthernet1/1
Protocol: igmp, UpTime: 00:12:07, Expires: -
(10.110.6.100, 225.1.1.1)
RP: 10.1.1.1 (local)
Protocol: pim-sm, Flag: SPT 2MSDP ACT
UpTime: 00:40:22
Upstream interface: GigabitEthernet2/0
Upstream neighbor: 10.110.4.2
RPF prime neighbor: 10.110.4.2
Downstream interface(s) information:
Total number of downstreams: 1
1: GigabitEthernet1/1
Protocol: pim-sm, UpTime: - , Expires: -
SA Message Filtering Configuration
Network requirements
•
As shown in
, three PIM-SM domains exist in the network, and OSPF runs within and among
the domains to provide unicast routing.
•
Configure respective Loopback 0 of Device A, Device C and Device D as a C-BSR and C-RP in the
respective PIM-SM domain.
•
Set up an MSDP peering relationship between Device A and Device C and between Device C and
Device D.
•
Source 1 sends multicast data to multicast groups 225.1.1.0/30 and 226.1.1.0/30, and Source 2
sends multicast data to multicast group 227.1.1.0/30.
•
Configure SA message filtering rules so that receivers Host A and Host B can receive only the
multicast data addressed to multicast groups 225.1.1.0/30 and 226.1.1.0/30, while Host can
receive only the multicast data addressed to multicast groups 226.1.1.0/30 and 227.1.1.0/30.
