20
Information about (Source, Group)-based SA filtering policy:
Import policy: none
Export policy: none
Information about SA-Requests:
Policy to accept SA-Request messages: none
Sending SA-Requests status: disable
Minimum TTL to forward SA with encapsulated data: 0
SAs learned from this peer: 0, SA-cache maximum for the peer: none
Input queue size: 0, Output queue size: 0
Counters for MSDP message:
Count of RPF check failure: 0
Incoming/outgoing SA messages: 0/0
Incoming/outgoing SA requests: 0/0
Incoming/outgoing SA responses: 0/0
Incoming/outgoing data packets: 0/0
Inter-AS Multicast Configuration Leveraging Static RPF Peers
Network requirements
•
As shown in
, there are two ASs in the network, AS 100 and AS 200 respectively. OSPF is
running within each AS, and BGP is running between the two ASs.
•
PIM-SM 1 belongs to AS 100, while PIM-SM 2 and PIM-SM 3 belong to AS 200.
•
Each PIM-SM domain has zero or one multicast source and receiver. OSPF runs within each domain
to provide unicast routes.
•
PIM-SM 2 and PIM-SM 3 are both stub domains, and BGP or MBGP is not required between these
two domains and PIM-SM 1. Instead, static RPF peers are configured to avoid RPF check on SA
messages.
•
It is required that the respective Loopback 0 of Device B, Device C and Device E be configured as
a C-BSR and C-RP of the respective PIM-SM domains.
•
It is required that Device C and Device E be configured as static RPF peers of Device B, and Device
B be configured as the only static RPF peer of Device C and Device E, so that any device can receive
SA messages only from its static RPF peer(s) and permitted by the corresponding filtering policy.
