9
To do... Use the command... Remarks
Configure an IGMP version globally version version-number
Optional
IGMPv2 by default
Configuring an IGMP version on an interface
Follow these steps to configure an IGMP version on an interface:
To do... Use the command... Remarks
Enter system view system-view —
Enter interface view
interface interface-type
interface-number
—
Configure an IGMP version on the
interface
igmp version version-number
Optional
IGMPv2 by default
Configuring Static Joining
After an interface is configured as a static member of a multicast group or a multicast source group, it will
act as a virtual member of the multicast group to receive multicast data addressed to that multicast group
for the purpose of testing multicast data forwarding.
Follow these steps to configure an interface as a statically connected member of a multicast group or a
multicast source and group:
To do... Use the command... Remarks
Enter system view system-view —
Enter interface view
interface interface-type
interface-number
—
Configure the interface as a static
member of a multicast group or a
multicast source and group
igmp static-group
group-address [ source
source-address ]
Required
An interface is not a static member
of any multicast group or multicast
source and group by default.
NOTE:
•
Before you can configure an interface of a PIM-SM device as a static member of a multicast group or a
multicast source and group, if the interface is PIM-SM enabled, it must be a PIM-SM DR; if this interface
is IGMP enabled but not PIM-SM enabled, it must be an IGMP querier. For more information about
PIM-SM and a DR, see PIM Configuration in the IP Multicast Volume.
• As a static member of a multicast group or a multicast source and group, the interface does not respond
to the queries from the IGMP querier, nor does it send an unsolicited IGMP membership report or an
IGMP leave group message when it joins or leaves a multicast group or a multicast source and group.
In other words, the interface will not become a real member of the multicast group or the multicast
source and group.
