CPU
Z8S180, 18. 432 MHZ clock
ELECTRICAL
Memory
CAMBASIC, 32K ROM (U1). Mapped per below.
Prog ram ming and data is 128K R AM (U2). Expand able
to 512K by installing part number 1039.
Program s are stored in 128K Flash type EPRO M (U3).
Expandable to 512K by installing part number 1301.
D i gi ta l I / O
T h e RP C - 2 35 0 ha s 48 d ig it a l I / O li ne s fr o m 82 C 5 5 I C .
24 are from J2, which is a general purpose port. The
other 24 are from J3. J3 has 8 high curre nt outputs,
which may be jumpered for inputs. Keypad port J5 uses
8 of the 24 lines. LCD display port J6 uses another 8.
The specifications below are for all digital I/O except for
the eight high current lines at J3.
Drive curr ent 2.5 mA . maximum per line,
sink or source. TTL
compatible.
Output low voltage 0.45V m ax at 2.5 mA , 1V
max at 15 mA. for opto rack.
Output high v olts 2.4V m inimum, sink or source
at rated cu rren t.
All digital input lines are TTL compatible.
High cu rrent ou tput at J3
8 of the 24 lines can drive up to 500 mA. at 50V. Refer
to CHAPTER 6, D IGITAL AND OPTO PORTS for
limitations.
Analog input(A/D)
Channels:
8
Ranges: 0-5V, ±2. 5V
Resolution: 12 bits (4096 counts)
Accuracy: ±3 counts + 3 counts offset
Type: Single ended or pseudo differential
Conversion time: 500 m icro-seconds in CAM BASIC
Analog voltage output(D/A) (option)
Channels:
2
Ranges: 0-5V, ±5V, 0-10V
Resolution: 12 bits (4096 counts)
Accuracy: ±3 counts + 3 counts offset
Cur rent outpu t: 5 mA. for accuracy
Settling time: 2 micro-seconds
4-20 mA. output(option)
Channels:
2 (each requires its own D/A ),
non-isolated
Input voltage: 12V to 30V or use on c ard supp ly
(
. 15V available)
Keypad input
10 lines accept a 16 to 24 position matrix keypad.
S c an n in g an d de b ou n ce p er f or m e d i n C A M B A SI C .
Uses 8 lines from J3. 24 position uses additional 2 lines
from J3.
Serial ports
Two RS-232D serial ports. COM1 has TxD and RXD
only. C OM2 also has RTS and C TS lines.
Prog ram mable ba ud rates fr om 600 to 3 8.4 K, 7 or 8 data
bits, par ity even, odd , or none, 1 or 2 stop bits.
F l as h EP R O M
Accepts Atmel 29C010A , 29C 040A or equivalent
P E PR O M.
Size:128K (29C010A) or 512K (29C040A)
Speed:120ns or faster.
Watchdog timer, reset
Watch dog timer resets card for 150 ms minimum when
enabled. Push button reset included.
Input power
+ 5VDC ±5% at 375 ma.
+ 12V at 250 mA. (RPC-2350G)
Current draw for 7-30V input depends upon applied
voltage. 7V supply draws more current (about 420 mA)
than 12V (about 200 ma).
Current consumption does not include any opto-modules
or other acc essories.
Output power
+ 5V at P2: 750 mA. with 7 to 30V input at “7-30V”
terminal on P2, W8 jumpered.
±12V at J7 Up to 40 mA. @ + 12, 20 mA. @ -12V
Note: Subtract any curr ent used by analog
outputs.
