5.3
Installing the servo amplifier
5
Installation
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
5-4
Fig. 5-2:
Installing the servo amplifier in a control cabinet
Cable duct
Control cabinet door
Mounting plate
conductive (zinc plated)
Hexagon socket cylinder
head screw DIN 912
>40
>75
>95
>55
45
75
45
2
>2.5
>75
308
>50
M5
>285
>110
75
