4.6 Implementation of stop categories
4 Function Description
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
4-62
P
M
= (M
0
* n
n
) / 9550
where:
` P
M
: Motor output [kW]
` M
0
: Standstill torque [Nm]
` n
n
: Rated speed [1/min]
4.6.3 Stop Category 2
Stop Category 2 4- ][Funktion_Stopp_2
The machine receives the operational stop command (disable) and
brakes the drive using the set braking ramp (STOPMODE and ACT-
FAULT parameters set to “1”).
` The drive is braked in a controlled manner as it comes to a stop. If the
speed VEL0 (see timing diagram in the section entitled “Switch on/
switch off behaviour”) drops below the set value, the holding brake is
applied and the inverted rectifier is shut down. In this case, the mains
voltage is maintained.
` If the mains is switched off, not only is a controlled braking procedure
initiated but the mains voltage is galvanically isolated from the holding
brake after a delay, which can be set on the timer.
5 kW - 10 kW 2.7
Ω
(110 W) 1000 V
10 kW - 20 kW 1
Ω
(300 W) 1000 V
20 kW - 40 kW 0.33
Ω
(600 W) 1000 V
Motor output P
M
Motor circuit brake resistor R
M
