7.5
Messages/errors
7
Commissioning
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
7-14
7.5
Messages/errors
7500
Messages/errors
7-
7.5.1
Status messages
Status messages
7-
][Inbetrieb_Meldung_Status
Status messages on the LED display indicate the operating status of the
servo amplifier.
7.5.2
Error messages
Error messages
7-
][Inbetrieb_Meldung_Fehler
Error are shown on the LED display with an error number. If an error oc-
curs, the BTB contact opens. The output stage of the servo amplifier
shuts down (motor is torque-free). The motor holding brake is activated.
No.
Error message
Description
E/S/
A/P
Status messages
Status message, no error
. . .
Status message
Amplifier updating the start configuration
-
Status message
Status message, no error, programming mode
- S -
STO-ENABLE
STO-ENABLE input = 0 V (if the drive is shut
down)
CCC
SD card
Problem when accessing the SD card
No.
Error message
Description
F01
Heatsink temperature
Heatsink temperature too high (default: 80?)
F02
Overvoltage
Overvoltage in the intermediate circuit. Limit
value depends on the mains voltage
F03
Drag error
Message from the position controller
F04*
Feedback
Open circuit, short circuit, earth fault
F05
Undervoltage
Undervoltage in the intermediate circuit (de-
fault: 100 V)
F06
Motor temperature
Temperature sensor defective or motor tem-
perature too high
F07*
Internal voltage
Internal supply voltages faulty
F08*
Overspeed
Motor runs away, speed higher than permitted
F09*
EEPROM
Check sum error
F10
Reserved
Reserved
F11*
Motor brake
Open circuit, short circuit, earth fault
F12
Motor phase
Motor phase missing (open circuit or similar)
F13
Ambient temperature
Ambient temperature too high
F14*
Output stage
Fault in the power output stage
F15
I²t max.
I²t maximum value exceeded
F16
Mains BTB
2 or 3 infeed phases missing
